Kwaliteit Breedte 400 mm PCB zuiver geleidende koperen tape fabriek

Breedte 400 mm PCB zuiver geleidende koperen tape

Plaats van herkomst: CHINA

Merknaam: OEM

Certificering: ISO / SGS / RoHS

Minimale bestelhoeveelheid: 50kg

Prijs: Bespreekbaar

Tags:

rode koperfolietape

EMI de folieband van het beveiligingskoper

PCB geleidende kleefband van koper

Sollicitatie:	Elektronisch	Breedte:	Max.400MM
Materiaal:	Rood koper	Cijfer:	Puur koper
Cu (min):	99.90%	Legering of niet:	Is legering
Behandeling:	In reliëf	Dikte:	0,018 mm ~ 1,2 mm
Functie:	hoge weerstand	Opmerking:	enkelgeleid/dubbelgeleid
Gebruik:	Isolatie
Markeren	400 mm geleidende koperen tape , 0.018mm geleidende koperen tape , 1.2 mm geleidende koperen tape

Productbeschrijving

Breedte 400 mm PCB Pure Geleidende Zelfklevende Koper Tape

Specificaties van koperfoliepapier:

1) Kwaliteit: c11000,C12200
2) Koper: cu min.99,90%
3) Dikte: 0,018-1,2 mm
4) Breedte: max. 400 mm
5) Rolgewicht: 6,5 kg/mm
6) Chemische samenstelling: Cu >99,90% p:0,015%-0,040%
7) Temper: O, 1/4H, 1/2H, H O : HV100
8) Elektrische geleidbaarheid 20°C: C11000 >97% ,C12200 >80%

Kwaliteit- en fabricage-informatie:

Chinese Kwaliteit	Buitenlands Vergelijkbaar Merk
	Internationaal	VS	JAPAN	VK	DUITSLAND
	(ISO)	(ASTM)	(JIS)	(BS)	(DIN)
T2	Cu-ETP	C11000	C1100	C101	R-Cu57
TP2	Cu-DHP	C12200	C1220	C106	SI-CU

Kwaliteit	Chinese Staat	Specificatie	Treksterkte	Rek	Vickers Hardheid
T2	M	Dikte: 0,005-1,2 mm Breedte: (Max)400mm Rolgewicht: 6,5 kg/mm	>205	>30	-
T2	Y4		215-275	>25	55-100
TP2	Y2		245-345	>8	75-120

Eigenschappen:

1) Goede viscositeit, koudebestendig
2) Mechanische weerstand, vochtbestendig
3) Hoge thermische geleidbaarheid, olie- en zuurbestendig
4) Verouderingsbestendig
5) Vlamvertragend
6) Gemakkelijk te scheuren

Toepassingen:

1) Elektrische en elektrische veren, schakelaars
2) Lead frames
3) Connectoren en oscillatieriet
3) PCB-veld
4) Communicatiekabel
5) Kabelarmering
6) Mobiele telefoon moederbord
7) Ion batterij productie lamineren met PI-film
8) PCB-collector (elektrode-achterkant) materialen

Breedte 400 mm PCB zuiver geleidende koperen tape 0
